Key Features & Performance
- SEISMIC Rx Suspension System saves time and money; Armstrong offers an ICC-ES approach to installations (ESR-1308)
- PEAKFORM profile increases strength and stability for improved performance during installation
- SUPERLOCK main beam clip is engineered for a strong, secure connection and fast, accurate alignment confirmed with an audible click; easy to remove/relocate
- Hot-dipped galvanized coating inhibits red rusting better than electrogalvanized or painted systems
- Rotary-stitched during manufacture for additional torsional strength and extra stability during installation
- FIRE GUARD options offer UL design fire-rated performance
- Blizzard White powder-coated finish coordinates with CALLA, OPTIMA, ULTIMA, and LYRA ceiling panels for a clean, seamless, monolithic installed visual.
24mm
Hot-dipped Galvanized Steel with Aluminum Cap
Category D, E & F
DEF
Intermediate Duty
May be wiped following CDC recommendations using EPA disinfectant cleaners per Armstrong Cleaning & Disinfecting Guidelines
May be sprayed following CDC recommendations using EPA disinfectant cleaners per Armstrong Cleaning & Disinfecting Guidelines
May be fogged following CDC recommendations using EPA-approved disinfectant cleaners per Armstrong Cleaning & Disinfecting Guidelines
Recyclable/Extended Producer Responsibility
|
Recycled Content
|
Energy Management
|
Sourcing of Raw Materials
|
Construction Waste
|
Material Ingredient Reporting
|
Regional Materials
Location Dependent
|
Low emitting/materials
|
Design for Flexibility
|
Lighting Quality
|
EPD
|
Acoustics
|
Biobased Materials
|
Colors & Options
Color shown may vary from actual product.
40 PRELUDE XL 15/16" Exposed Tee Products
Sustain = Items included in the SUSTAIN portfolio
Item # | Description | Drawing | Dimensions | Rout/Slot Spacing and UOM | Color | |||
---|---|---|---|---|---|---|---|---|
Main Beam | ||||||||
7300Sustain | 12ft ID Main Beam | 6" |
| Create Specification | ||||
730098HRC | 98in SingleSpan - Prelude Peak Plus | 6" |
| Create Specification | ||||
7301Sustain | 12ft Heavy Duty Main Beam | 6" |
| Create Specification | ||||
730102HRC | 102in SingleSpan - Prelude Peak Plus | 6" |
| Create Specification | ||||
730144HRC | 12ft SingleSpan - Prelude Peak Plus | 6" |
| Create Specification | ||||
7301HRCSustain | 12ft HD Main Beam | 6" |
| Create Specification | ||||
7302Sustain | 10ft ID Main Beam | 6" |
| Create Specification | ||||
7305Sustain | 140in ID Main Beam | 10" |
| Create Specification | ||||
7306 | PRELUDE 11' ID MB TZ | 6" |
| Create Specification | ||||
7307 | PRELUDE 10.5' HD MB TZ |
| Create Specification | |||||
734032Sustain | 3600mm ID Main Beam | 150mm |
| Create Specification | ||||
734033Sustain | 3600mm HD Main Beam | 150mm |
| Create Specification | ||||
7376Sustain | 90" Main Beam Prelude XL, Routs 6" OC |
| Create Specification | |||||
7396Sustain | 114" Main Beam Prelude XL, Routs 6" OC |
| Create Specification | |||||
312051Sustain | 600mm Cross Tee |
| Create Specification | |||||
312451GSustain | 300mm Cross Tee |
| Create Specification | |||||
313051Sustain | 1200mm Cross Tee |
| Create Specification | |||||
XL7148 | 4ft Cross Tee | 12" |
| Create Specification | ||||
XL7304Sustain | Prelude 4" XL 15/16" No Routs White |
| Create Specification | |||||
XL7306Sustain | 6" Cross Tee, no routs |
| Create Specification | |||||
XL731036 | 1ft Cross Tee |
| Create Specification | |||||
XL7318Sustain | 1ft Cross Tee |
| Create Specification | |||||
XL7328Sustain | 2' Cross Tee |
| Create Specification | |||||
XL7330Sustain | 3ft Cross Tee |
| Create Specification | |||||
XL7340Sustain | 4ft Cross Tee | 12" |
| Create Specification | ||||
XL7341Sustain | 4ft Cross Tee |
| Create Specification | |||||
XL7341HRCSustain | 4ft Cross Tee |
| Create Specification | |||||
XL7342Sustain | 4' Cross Tee | 12" |
| Create Specification | ||||
XL7348Sustain | 4ft Cross Tee | 12" |
| Create Specification | ||||
XL7357Sustain | 5ft Cross Tee - Routs 6in OC | 6" |
| Create Specification | ||||
XL7358Sustain | 5ft Cross Tee - Routs 20in OC | 20" |
| Create Specification | ||||
XL7368Sustain | 20in Cross Tee |
| Create Specification | |||||
XL7378Sustain | 30in Cross Tee |
| Create Specification | |||||
XL7379BL | 30” Prelude WOODWORKS Torsion Spring Cross Tee |
| Create Specification | |||||
XL7380Sustain | 8ft Cross Tee | 12" |
| Create Specification | ||||
XL7390Sustain | 6ft Cross Tee | 12" |
| Create Specification | ||||
XL7398Sustain | 18in Cross Tee |
| Create Specification | |||||
XL8320Sustain | 2ft Cross Tee |
| Create Specification | |||||
XL8320HRCSustain | 2ft Cross Tee |
| Create Specification | |||||
CLP7301Sustain | Continuous Load Path for Prelude XL 15/16" Exposed Tee: CLP7301 |
| Create Specification |
