Key Features & Performance
- Standard size – 30" × 30"
- Simple plenum access with easy-to-access torsion spring design
- Interior panels feature swing down accessibility
- System utilizes a locking clip to pevent unintended panel removal
- Available in M1, unperforated and M17 perforated options:
- M17 = 0.90 NRC with factory-applied fleece and 1" fiberglass infill
- Part of the SUSTAIN portfolio, and meets the most stringent industry sustainability compliance standards today
- Panels are designed for easy installation on pre-slotted heavy-duty, extruted aluminum main beams and cross tees - 30" O.C layout
- FASTPEEL panel featuring a faster and easier-to-remove protective film
A measure for rating the overall sound absorption of a material when used in an enclosed architectural space where sound is reflected at many angles of incidence. A ceiling system with an NRC < 0.50 is low performance, an NRC > 0.70 is high performance.
A high light reflective ceiling – LR 0.83 or greater, per ASTM E1477-98 as referred to in ASTM E1264-98 – makes lighting systems, especially indirect lighting, more effective while further reducing energy costs and consumption. LR values apply to White panels only.
Ceiling panels with BIOBLOCK performance resist the growth of mold and mildew on the panel surface.
Ceiling panels with BIOBLOCK Plus performance resist the growth of odor and stain-producing bacteria as well as mold and mildew on the ceiling panel surface.
Product resists water for 15 minutes allowing proper cleaning for infection control.
Excellent resistance to dirt and/or grease for lasting value and performance.
Surface impact based on the Striking Ball Impact Test, modified ASTM D1037 procedure.
Excellent resistance to surface scratching, scuffing or chipping as per Hess Rake Test.
Offers superior wash resistance without compromising panel finish integrity, using a washability tester as per ATSM D4828.
Withstands up to 150 scrub cycles using a scrubbability tester as per ATSM 02486.
May be fogged following CDC recommendations using EPA-approved disinfectant cleaners per Armstrong Cleaning & Disinfecting Guidelines
May be sprayed following CDC recommendations using EPA disinfectant cleaners per Armstrong Cleaning & Disinfecting Guidelines
May be wiped following CDC recommendations using EPA disinfectant cleaners per Armstrong Cleaning & Disinfecting Guidelines
|
Recyclable/Extended Producer Responsibility
|
Recycled Content
|
|
Energy Management
|
Sourcing of Raw Materials
|
|
Construction Waste
|
Material Ingredient Reporting
|
|
Regional Materials
Location Dependent
|
Low emitting/materials
|
|
Design for Flexibility
|
Lighting Quality
|
|
EPD
|
Acoustics
|
|
Biobased Materials
|
