DESIGNSTACKZ Ceiling System

Experience the beauty of geometric, 90-degree precision in ceiling design.

Key Features & Performance

  • DESIGNSTACKZ is part of the SUSTAIN portfolio and meets the most stringent industry sustainability compliance standards today
  • CLEANASSURE family of products – includes disinfectable panels, suspension systems, and trim​
  • Good combination of sound absorption and sound blocking: 0.70 NRC and 37 CAC
  • PEAKFORM profile increases strength and stability for improved performance during installation
  • Hot-dipped galvanized coating inhibits red rusting better than electrogalvanized or painted systems
  • Multi-directional 90-degree bracket
  • 1-11/16" web height keeps components vertical and stable at light fixture interface
  • 10-Year Limited System Warranty
Material
Materials
Mineral Fiber
Acoustics
Sound Absorption (NRC)

A measure for rating the overall sound absorption of a material when used in an enclosed architectural space where sound is reflected at many angles of incidence. A ceiling system with an NRC < 0.50 is low performance, an NRC > 0.70 is high performance.

0.70
Sound Blocking (CAC)

A measure for rating the performance of a ceiling system as a barrier to airborne sound transmission through a common plenum between adjacent closed spaces. A ceiling system with a CAC < 25 is considered low performance, whereas one with CAC of 35 or higher is high performance.

37
Articulation Class (AC)

Product has AC (Articulation Class) 170 or greater.

170
Fire
Fire Performance
Class A
Light
Light Reflectance

A high light reflective ceiling – LR 0.83 or greater, per ASTM E1477-98 as referred to in ASTM E1264-98 – makes lighting systems, especially indirect lighting, more effective while further reducing energy costs and consumption. LR values apply to White panels only.

85%
Anti-Microbial
Mold/Mildew Resistance

Ceiling panels with BIOBLOCK performance resist the growth of mold and mildew on the panel surface.
Ceiling panels with BIOBLOCK Plus performance resist the growth of odor and stain-producing bacteria as well as mold and mildew on the ceiling panel surface.

BIOBLOCK
Humidity
Sag/Humidity Resistance

Ceiling panels maintain humidity and sag resistance.

HUMIGUARD Plus
Durability
Soil Resistance

Excellent resistance to dirt and/or grease for lasting value and performance.

Impact Resistance

Surface impact based on the Striking Ball Impact Test, modified ASTM D1037 procedure.

Disinfectability
Fog

May be fogged following CDC recommendations using EPA-approved disinfectant ​cleaners per Armstrong Cleaning & Disinfecting Guidelines​

Order a sample of this product and we'll ship to your door – free.
Complimentary ceiling design & pre-construction service.
Sustainability Profile
Sustainable Product Search Tool
Recyclable via the Armstrong Ceilings Recycling Program
LEED  •  WELL  •  Living Building Challenge
Recyclable/Extended Producer Responsibility
Recycled Content
Energy Management
Sourcing of Raw Materials
Construction Waste
Material Ingredient Reporting
Regional Materials
Location Dependent
Low emitting/materials
Design for Flexibility
Lighting Quality
EPD
Acoustics
Biobased Materials
